Mouse in Select Mode

►

To create a new event in Select mode, double-click at the desired location in the back-

ground of the Event area.

Mouse in Paint Mode

►

To create a new event in Paint mode, simply click at the desired location. Click and hold

your mouse and move the cursor horizontally to quickly create a series of events.

You cannot create events with your mouse in Erase mode.

Creating Events Beyond the Pattern’s End

If you create an event beyond the end of the Pattern in the Event area, the Pattern is automati-

cally extended to the next Pattern Grid division after the new event so that the Pattern includes

this new event.

For more information on the Pattern Length and the Pattern Grid, see section ↑7.1.6, Ad-

justing the Pattern Grid and the Pattern Length.

7.4.2.1 Creating Events/Notes on Your Controller

Your controller offers numerous ways to create events — on your controller this is referred to as

“recording Patterns.” For details on this please refer to section ↑7.2, Recording Patterns in Re-

al Time and ↑7.3, Recording Patterns with the Step Sequencer.

7.4.3 Selecting Events/Notes

MASCHINE provides you many ways to select events/notes in your Pattern. This notably allows

you to precisely define which events your next edits will be applied to.

In the software you can select events with your mouse only if Select mode is selected in the

Edit Mode selector:

Click the cursor icon on the left to select events with your mouse.

Working with Patterns

Editing Events

MASCHINE STUDIO - Manual - 288
