Selection Tool Description
Button 5/6 (UP/DOWN)
Switch the focus to the previous/next Sound in order to add or remove some of its
notes to/from the selection. The name of the selected Sound is indicated under
the EVENTS label in the top left corner of the left display.
Knob 1/2 (START/END)
Define the selection’s start and end points in the timeline for the focused Sound.
All notes within this time interval and within the pitch interval defined by LOW and
HIGH (see below) are included into the selection.
Knob 3/4 (LOW/HIGH)
Define the selection’s lowest and highest pitch for the focused Sound. All notes
within this pitch interval and within the time interval defined by START and END (see
above) are included into the selection.
Page buttons Drop the current selection and select the previous/next individual event for the fo-
cused Sound.
By combining these tools you can precisely define the selection of notes you want to edit.
7.4.4 Editing Selected Events/Notes
Once you have selected particular events, you can edit them in various ways.
In the software you can edit events with your mouse only if Select mode is selected in the Edit
Mode selector:
Click the cursor icon on the left to select events with your mouse.
Action Function
Editing Selected Notes
Drag note horizontally Moves selected notes in time according to the Step Grid (see quan-
tizing rules below).
[Ctrl] + drag note horizontally
(Mac OS X: [Cmd] + drag note)
Freely moves selected notes in time (overrides the Step Grid quanti-
zation).
[Alt] + drag note Duplicates selected notes. When you drag horizontally, the copies
are moved in time according to the Step Grid (see quantizing rules
below).
