Action Function
Drag left/right note border Moves the start/end of selected notes according to the Step Grid,
thereby resizing the notes (see quantizing rules below).
[Ctrl] + drag left/right note border
(Mac OS X: [Cmd] + drag left/right
border)
Freely moves the start/end of selected notes (overrides the Step Grid
quantization), thereby resizing the notes.
Drag note vertically Group view: Moves selected notes to another Sound of the Group.
Keyboard view: Transposes selected notes.
Double-click note Deletes selected notes.
Right-click (Mac OS X: [Ctrl]-click) Deletes selected notes.
If multiple notes are selected, mouse actions can be performed on any of the selected notes —
they will apply to all selected notes.
If you perform any of the actions listed above on a note not included in the current selection,
the selection is dropped and the note you are editing will be the only note affected by your
edit.
MASCHINE also provides an exhaustive set of keyboard shortcuts to edit your events! For a
detailed list please refer to the Hardware Control Reference document available in the Help
menu of MASCHINE’s Application Menu Bar and in the Help submenu of the MASCHINE
menu.
Quantization when Editing a Single Event/Note
By default, all dragging actions on the time axis are quantized according to the Step Grid:
▪ When you drag a note (or its duplicate) horizontally, its original offset with the Step Grid
is preserved, unless you drag the note near a grid line — in that case it will snap to the
grid.
▪ When you resize a note by dragging its start/end border, the new start/end border will snap
to the Step Grid.
To override the quantization and freely adjust the note position or size, hold [Ctrl] ([Cmd]
on Mac OS X) while dragging!
Working with Patterns
Editing Events
MASCHINE STUDIO - Manual - 294
