Editing Tool Description
Knob 1 (POSITION)
Nudges selected events, i.e. shifts selected events on the timeline according to
the Nudge Grid (the events’ offsets relative to the Nudge Grid are preserved). Hold
SHIFT while you turn the knob to temporarily override the Nudge Grid quantization
and adjust the positions in extremely small increments. See section ↑7.1.7, Ad-
justing the Step Grid and the Nudge Grid for more information on the Nudge Grid.
If one event only is selected, its position is shown under POSITION. If several events
are selected, the field shows (MULTI).
See also the alternate method described below.
Knob 2 (LENGTH)
Moves the end of the selected events according to the Step Grid (the offset of
each event’s end relative to the Step Grid is preserved). Hold SHIFT while you turn
the knob to temporarily override the Step Grid quantization and adjust the lengths
in extremely small increments. If the events have different lengths, the length dif-
ferences are retained as long as no event becomes shorter than one step.
If one event only is selected, its length is shown under LENGTH. If several events are
selected, the field shows (MULTI).
Knob 3 (PITCH)
Transposes the selected events by semitones.
If one event only is selected, its pitch is shown under PITCH. If several events are
selected, the field shows (MULTI).
See also the alternate method described below.
Knob 4 (VELOCITY)
Adjusts the velocity of the selected events. If the events have different velocities,
the velocities differences are retained as long as the limits (0 and 127) are not
reached. If one event only is selected, its velocity is shown under VELOCITY. If sever-
al events are selected, the field shows (MULTI).
You can also use these editing functions to quickly create variations of your Patterns during
a live performance!
The following paragraphs will show you alternate editing functions available in the EDIT sec-
tion of your controller. These functions also work outside Select mode.
Nudge Events and Notes
Nudging allows you to shift selected events by the Nudge Grid resolution (the events’ offsets
relative to the Nudge Grid are preserved).
Working with Patterns
Editing Events
MASCHINE STUDIO - Manual - 298
