head position. In Group view the events copied from the topmost Sound in the Sound
List are pasted onto the focused Sound, and all copied events retain their position rel-
ative to each other, both on the time axis and on the vertical axis (Sound List in Group
view, pitches in Keyboard view).
7.4.6.1 Cut, Copy, and Paste Events/Notes on the MASCHINE STUDIO Controller
To copy and paste selected events from your controller, use the buttons of the EDIT section
above the jog wheel:
The COPY, PASTE, and CLEAR button in the EDIT section.
1. To copy the selected events, press COPY.
2. If you want to cut the selected events before pasting them, CLEAR to delete the original
events.
3. To paste them, press PASTE.
→
The events will be pasted according to the same rules as when using the keyboard short-
cuts in the software (see above). If no event is selected, all displayed events will be affec-
ted: in Keyboard view these are all events of the focused Sound; in Group view these are
all events of all Sounds within the Group (see section ↑7.1.5, Group View and Keyboard
View for more information on Group view and Keyboard view).
You can also copy events from one Pattern to another: to do this, copy the selected events,
select the Pattern you want to copy them to and then paste them.
Working with Patterns
Editing Events
MASCHINE STUDIO - Manual - 304
