▪ Temporary: The modified value is valid only until the end of the Clip: When the Scene is
looped or when playback is restarted, the parameter value is reset to its non-modulated
value.
▪ Relative (knobs only): For continuous parameters (these parameters are controlled by a ro-
tary knob in the software), the new parameter value is defined as deviation from the ac-
tual value. Note that for selectors and buttons, modulation defines instead absolute val-
ues.
Modulation vs. Automation
Although both deal with automatic change of MASCHINE parameters, modulation and automa-
tion have to be distinguished. The following table summarizes the main differences:
Modulation Automation
Source of control Internal (e.g., changes recorded via
Auto-write)
External (e.g., an external MIDI se-
quencer or an automation track in
your host)
Duration of the change Temporary (until the end of the
Clip)
Permanent
Target parameters At the Sound and Group levels only
(see below)
At all levels (Sound, Group, and
Master)
Nature of the change (continuous pa-
rameters only)
Relative (defines a deviation to the
non-modulated value)
Absolute (defines a new value re-
gardless of the non-automated val-
ue)
This section describes how to use modulation in MASCHINE — for more information on us-
ing automation, please refer to section ↑8.2.2, Controlling Parameters via MIDI and Host
Automation.
Please note that modulation and automation are not mutually exclusive: You can modulate a
parameter in MASCHINE and automate it (e.g., from your host) simultaneously! As a result,
the parameter value will deviate (according to the recorded modulation) from its moving value
defined by the automation.
Working with Patterns
Recording and Editing Modulation
MASCHINE STUDIO - Manual - 307
