◦ Group’s Input properties: the Root Note knob in the MIDI page.
At the Sound and Group level the same parameters can be automated and modulated. For
more information on automation please refer to section ↑8.2.2, Controlling Parameters via
MIDI and Host Automation.
Also note that your Macro Controls can be modulated if, and only if, their target parameters
can be modulated themselves by design. For more information on Macro Controls please refer
to section ↑8.3, Creating Custom Sets of Parameters with the Macro Controls.
7.5.2 Recording Modulation
In the software in Arrange view, if you take a closer look at the knobs in the Parameter pages
of the Control area you will notice they have an outer ring that changes its color to light grey as
soon as you hover over it with the cursor.
Drag the outer ring of the knobs to record modulation.
►
To record modulation for a knob in real time, click its outer ring and then drag it up and
down during playback.
→
Your movement are recorded into the Pattern and will be recalled as the playback is loo-
ped.
As soon as you create modulation for a parameter, the following happens:
▪ On the outer ring of the knob, the colored section (usually indicating the current parame-
ter value) is replaced by a little segment indicating the modulated value. During playback
this little segment follows the movement you have just recorded. The non-modulated val-
ue of the parameter is still indicated by the little white segment on the knob itself. Since
modulation is defined relative to this non-modulated value, you can turn the knob to de-
fine the reference value from which the recorded modulation will deviate.
