You can pin Auto-write mode by pressing SHIFT + AUTO. This allows you to have both

hands free to tweak Knobs 1–8 and record modulation for several parameters simultane-

ously! When you’re done, press AUTO again to stop recording modulation.

If you want to discard the modulation you recorded and try again:

►

Hold ERASE and again turn the Knob you used to record modulation to delete all modu-

lation events for this parameter.

You can also delete all modulation events for all parameters of the channel:

►

Press SHIFT + CLEAR (CLR AUTO) to delete all modulation for all parameters of the fo-

cused Sound or Group.

You can also record modulation from the step sequencer! See ↑7.3.3, Recording Modula-

tion in Step Mode for more information.

7.5.3 Creating and Editing Modulation in the Control Lane

You can also create, select, and edit individual modulation points in the Modulation pane of the

Control Lane.

Displaying the Modulation Pane in the Control Lane

1. To see and edit modulation for parameters of a Sound, click the desired Sound in the

Sound List (left of the Pattern Editor) and click the SOUND tab in the Control area.

2. To see and edit modulation for parameters of a Group, click the desired Group in the

Group List (left of the Arranger) and click the GROUP tab in the Control area.

3. If the Control Lane is not visible at the bottom of the Pattern Editor, click the up-pointing

arrow in the bottom left corner of the Pattern Editor to show it.

Working with Patterns

Recording and Editing Modulation

MASCHINE STUDIO - Manual - 311
