Resetting a Modulation Track
►
To reset the modulation track of a parameter, right-click ([Ctrl]-click on Mac OS X) the
desired entry in the Modulator List and select Reset Modulator at the top of the menu.
→
All modulation points are deleted in all Patterns of the Group and you can start designing
a new modulation for that parameter from scratch.
Re-Assigning a Modulation Track
►
To change the parameter assignment of a modulation track, right-click ([Ctrl]-click on
Mac OS X) the desired entry in the Modulator List and select another parameter from the
hierarchical menu as described above.
→
Upon your selection all modulation points are deleted and the track is assigned to the
new parameter. The previous parameter is not modulated anymore.
Removing a Modulation Track
►
To remove a modulation track, hover its entry in the Modulator List with the mouse and
click the little cross that appears on its right.
→
The modulation track and its entry in the Modulator List are removed from the Modula-
tion pane for all Patterns. The parameter is not modulated anymore.
7.6 Creating MIDI Tracks from Scratch in MASCHINE
Within MASCHINE you can create MIDI tracks from scratch for any Sound of your Project. MA-
SCHINE’s MIDI automation tracks can have two purposes:
Working with Patterns
Creating MIDI Tracks from Scratch in MASCHINE
MASCHINE STUDIO - Manual - 316
