If MASCHINE is running as a plug-in, the external stereo inputs Ext. 1–4 available in the
Source selector of the MAIN section will correspond to virtual inputs in your host. This al-
lows you to send mixer channels from your DAW to individual Sounds within MASCHINE,
for example. Please refer to your host documentation to find out how to route signals to the
virtual audio inputs of your MASCHINE plug-in.
As any Parameter page of any Channel properties or Plug-in, this page is also available on
your controller. To access it and change its parameters, simply use the common workflow
described in ↑2.3.3, Navigating Channel Properties, Plug-ins, and Parameter Pages in the
Control Area. Furthermore, you will find a step-by-step use case in ↑11.2, Applying Effects
to External Audio.
Configuring External Inputs for Sounds in Mix View
You can also easily send external audio to Sounds in MASCHINE’s Mixer:
1. Click the Mix View button on the left of the Arranger to switch from Arrange view to Mix
view:
2. Open the extended view of the Mixer by clicking the down-pointing arrow on the left of the
Mixer:
Audio Routing, Remote Control, and Macro Controls
Audio Routing in MASCHINE
MASCHINE STUDIO - Manual - 353
