This default behavior can be customized to your liking: You can adjust the level and panoramic
position of the channel output, or send it to the Cue bus for pre-listening. Furthermore, you
could send individual Sounds or whole Groups to other pairs of outputs on your audio interface
in order to process them separately at a later stage. The output routing configuration is done
on the Audio page of the Output properties for Sounds and Groups.
Here we describe here the Audio page of the Output properties for Sounds and Groups only.
The equivalent page for the Master will be described in section ↑8.1.4, Configuring the
Master and Cue Outputs of MASCHINE.
The Audio page of the Output properties (here for a Sound) in the software.
The AUDIO page of the Output properties (here for a Sound) on the controller.
Please refer to section ↑2.3.3, Navigating Channel Properties, Plug-ins, and Parameter Pa-
ges in the Control Area to know how to access the Audio page of the Output properties in
the software and from your controller.
Audio Routing, Remote Control, and Macro Controls
Audio Routing in MASCHINE
MASCHINE STUDIO - Manual - 356
