7. Set the pre/post state of the auxiliary output by clicking the Post (or Pre) label right under
the menu.
This is equivalent to setting the Order parameter described above.
8.1.4 Configuring the Master and Cue Outputs of MASCHINE
All channels routed to the Master are mixed together and processed by the Plug-ins loaded in
the Master, if any. The result is then sent to the Master output (that is, MASCHINE’s main out-
put).
Besides, all channels currently routed to the Cue bus for pre-listening are mixed together and
sent to the Cue output.
For more information on how to use the Cue bus, see section ↑9.2.6, Using the Cue Bus.
Using the Audio page of the Output properties for the Master you can select the outputs (on
your audio interface or in your host) for the Master and Cue outputs, and adjust their respec-
tive levels and panoramic positions.
The Audio page of the Output properties for the Master in the software.
Audio Routing, Remote Control, and Macro Controls
Audio Routing in MASCHINE
MASCHINE STUDIO - Manual - 365
