The AUDIO page of the Output properties for the Master on the controller.
Please refer to section ↑2.3.3, Navigating Channel Properties, Plug-ins, and Parameter Pa-
ges in the Control Area to know how to access the Audio page of the Output properties in
the software and from your controller.
Controls Description
AUDIO Section
Output Select where you want to send the master output of your MASCHINE Project.
Available options are the 16 external stereo outputs Ext. 1–16.
Level Adjust the overall volume level of the master output. This control is the same
as the Master Volume slider in the Header, at the top right corner of MA-
SCHINE’s window.
Pan Defines the panoramic position of the master output in the stereo field.
CUE Section
Output Select where you want to send the Cue bus of your MASCHINE Project. Availa-
ble options are the 16 external stereo outputs Ext. 1–16. By selecting a differ-
ent output from the one used for the main stereo output, you can effectively
pre-listen on this additional output (e.g., on your headphones) any channel(s)
currently sent to the Cue bus. To send a channel to the Cue bus, enable the
Cue switch in the Audio page of its Output properties (see section ↑8.1.2, Con-
figuring the Main Output of Sounds and Groups).
Level Adjust the level of the Cue output.
Pan Define the panoramic position of the Cue output in the stereo field.
Audio Routing, Remote Control, and Macro Controls
Audio Routing in MASCHINE
MASCHINE STUDIO - Manual - 366
