8.2 Using MIDI Control and Host Automation
MASCHINE provides you with flexible MIDI remote control and host automation facilities that
can be used in many situations.
Incoming MIDI and Host Automation
MASCHINE’s Master, Groups and Sounds can be controlled via MIDI and the host (when MA-
SCHINE is running as a plug-in), both globally and individually:
▪ By default, all MIDI data incoming on the enabled MIDI input port(s) will be received by
the focused Sound of the focused Group. See section ↑2.6.2, Audio and MIDI Settings –
Routing Page to know how to enable/disable MIDI input ports in MASCHINE.
▪ Triggering Sounds via MIDI notes: By default, incoming MIDI notes will trigger the focused
Sound. You can change this default behavior and map incoming MIDI notes differently in
order to adapt MASCHINE to your requirements. The appropriate MIDI settings can be
configured in the MIDI page of the Input properties, both for individual Sounds and for
entire Groups. These are described in section ↑8.2.1, Triggering Sounds via MIDI Notes.
▪ Controlling parameters via MIDI messages and host automation: You can control parameters
of Channel properties and Plug-ins in your channels (Sounds, Groups, and Master) via
MIDI messages and host automation (when MASCHINE is running as a plug-in). This is
described in section ↑8.2.2, Controlling Parameters via MIDI and Host Automation.
▪ Switching Plug-in Patches via MIDI Program Change messages: You can use MIDI Program
Change messages to recall particular patches (or programs, presets, etc.) for Native In-
struments and External Plug-ins loaded at the Sound level. This is described in section
↑8.2.3, Selecting VST/AU Plug-in Presets via MIDI Program Change.
When MASCHINE is running as a plug-in in a host, you can also trigger your Scenes using
MIDI notes or MIDI Program Change messages. Please refer to section ↑13.4, Triggering
Scenes via MIDI (MASCHINE Plug-in Only) for more information on this.
