Please refer to section ↑2.3.3, Navigating Channel Properties, Plug-ins, and Parameter Pa-
ges in the Control Area to know how to access the MIDI page of the Input properties in the
software and from your controller.
The MIDI input settings for Sounds and Groups provide following parameters:
Controls Description
MIDI Section
Active (plug-in mode only) Enables the MIDI note input for the selected Sound/Group (disabled by de-
fault). Please refer to your host documentation to know how to route MIDI sig-
nals to your MASCHINE plug-in. Note that when Active is disabled for both a
Sound and its parent Group, if the Sound is focused it will receive MIDI notes
sent by the host (default behavior for Sounds).
Source (stand-alone mode
only)
Selects the MIDI port on which the Sound or Group will receive MIDI notes.
Available entries are None (MIDI note input disabled, default setting), All
(MIDI notes are received on all enabled input ports), and each enabled MIDI
input port. You can enable the desired MIDI input ports of your MIDI interfaces
in the MIDI page of the Audio and MIDI Settings panel (see section ↑2.6.2,
Audio and MIDI Settings – Routing Page). Note that when None is selected for
both a Sound and its parent Group, if the Sound is focused it will receive MIDI
notes from all MIDI ports and on all MIDI channels.
Channel Selects the MIDI channel on which the Sound or Group will receive MIDI
notes. If you select All (default setting), the Sound or Group will receive MIDI
notes from all channels.
The Channel parameter of a Sound is also used when importing a multi-chan-
nel MIDI file to its Group — see section ↑7.8.3, Importing MIDI to Patterns for
more on this.
Root Note (Groups only) Defines the MIDI root note for the selected Group (C1 by default). The MIDI
root note and the upper 15 MIDI notes (from [Root Note] until [Root Note +
15]) will trigger the root note of Sound slot 1–16, respectively. Incoming MIDI
notes outside this range will be ignored by the Group.
The Root Note parameter is also used when importing a single-channel MIDI
file to the Group — see section ↑7.8.3, Importing MIDI to Patterns for more on
this.
Audio Routing, Remote Control, and Macro Controls
Using MIDI Control and Host Automation
MASCHINE STUDIO - Manual - 373
