The Automation pane of the Assignment area.

1. Click the down-pointing arrow in the bottom left corner of the Control area to reveal the

Assignment area underneath:

2. In the left part of the Assignment area, click the Automation tab:

→

The Automation tab lights up and the Automation pane appears on its right. You are now

ready to configure MIDI and host automation for the parameters in the current Parameter

page.

Once the Assignment area is open, when you switch to other Parameter pages the Assign-

ment area follows your selection: it always shows the assignments for the page currently

displayed above.

MASCHINE 1.x owners: In previous MASCHINE versions MIDI/host automation was only

possible via the Macro Controls. Now MIDI/host automation and Macro Controls are unrela-

ted: MIDI/host automation can be configured directly on parameters, independently of your

Macro Control assignments. Macro Controls now specifically serve as shortcuts (or “ali-

ases”) for parameters — see section ↑8.3, Creating Custom Sets of Parameters with the

Macro Controls for more information.

The Automation pane holds two tabs:

▪ MIDI tab: Click the MIDI tab to assign MIDI messages to automatable parameters. You can

then remote control and automate MASCHINE parameters from any MIDI-capable device

or software. Possible MIDI messages are Pitch wheel, Program Change, and MIDI CC 0–

127.

Audio Routing, Remote Control, and Macro Controls

Using MIDI Control and Host Automation

MASCHINE STUDIO - Manual - 378
