If there is already a MIDI assignment for the parameter, the new MIDI assignment will replace
the previous one. If you change your mind and don’t want to assign any new MIDI control,
while Learn is blinking click the Assignment field again or press [Esc] on your computer key-
board.
You cannot assign the same MIDI control to more than one parameter in MASCHINE: If a
MIDI control is already assigned to a parameter, when you assign it to another parameter
its first assignment is automatically deleted.
If you want to simply remove a MIDI assignment without recording a new one, do the following:
►
Right-click ([Ctrl]-click on Mac OS X) the non-empty Assignment field under a parameter
and select Unlearn in the menu to remove the MIDI assignment for that parameter.
→
The MIDI assignment is removed from the Assignment field and the parameter is not con-
trollable via MIDI anymore.
Of course, this procedure also works for Native Instruments and External Plug-ins loaded in
MASCHINE.
8.2.3 Selecting VST/AU Plug-in Presets via MIDI Program Change
If you have a Native Instruments or third-party VST/AU plug-in loaded in a Sound, you can re-
motely switch presets (or patches, programs, etc.) in your plug-in via MIDI Program Change
messages.
For this to work, your plug-in must reveal its presets (or a particular set of presets) to the host.
Each VST/AU instrument or effect might handle its presets (or patches, programs…) different-
ly. Please refer to the plug-in documentation to find out how to make its presets available to
the host.
