5. At the bottom of the channel strip of the Sound you want to configure, click the bigger
field left and select the desired MIDI port in the menu.
This is equivalent to setting the Dest. parameter described above.
6. Click the little field on its right to select a MIDI channel.
This is equivalent to the Channel parameter described above.
8.3
Creating Custom Sets of Parameters with the Macro Controls
Macro Controls enable you to control in one location a selection of parameters from different
sources. Available in every channel (Sounds, Groups, and Master), Macro Controls are very use-
ful for playing live since you can choose a set of parameters from various sources to manipu-
late on one screen without having to switch screens.
Audio Routing, Remote Control, and Macro Controls
Creating Custom Sets of Parameters with the Macro Controls
