Opening the Pages Pane in the Assignment Area
First of all, you need to open the Pages pane of the Assignment area for Macro properties. To
do this:
1. Select the Macro properties of the desired channel (Sound, Group, or Master) as descri-
bed in section ↑2.3.3, Navigating Channel Properties, Plug-ins, and Parameter Pages in
the Control Area.
2. Click the down-pointing arrow in the bottom left corner of the Control area to reveal the
Assignment area underneath:
3. Click the Pages tab in the left part of the Assignment area:
→
The Pages tab lights up and the Pages pane appears on its right. You are now ready to
assign Macro Controls to parameters.
Once the Assignment area is open, when you switch to other Parameter pages the Assign-
ment area follows your selection: it always shows the assignments for the page currently
displayed above.
The Pages tab can be clicked only for Native Instruments or External Plug-ins and for Mac-
ro properties. For all other Plug-ins and Channel properties, parameters and Parameter pa-
ges are not editable, and the Pages tab is grayed out and inactive. For more information on
how to assign parameters of Native Instruments or External Plug-ins to Parameter pages,
please refer to ↑6.3.3, Setting Up Your Own Parameter Pages.
When the Pages pane of the Assignment area is open, you will also notice a few changes in the
Control area above.
Audio Routing, Remote Control, and Macro Controls
Creating Custom Sets of Parameters with the Macro Controls
MASCHINE STUDIO - Manual - 392
