To open the channel’s context menu, right-click ([Ctrl]-click on Mac OS X) the back-
ground of the channel header:
Opening the context menu of a channel automatically sets the focus on that channel.
The channel’s context menu provides the exact same entries as in Arrange view.
Following management commands are available in the Mixer:
Management Command Action
Renaming channels Double-click the channel name in the header, type the desired name on
your computer keyboard, and press [Enter] to confirm (or [Esc] to cancel).
You can also open the channel’s context menu and select Rename.
See section ↑4.2.3, Renaming Sound Slots and ↑4.3.3, Renaming Groups.
Changing the channel’s color Open the channel’s context menu and select Color.
See section ↑4.2.4, Changing the Sound’s Color and ↑4.3.4, Changing the
Group’s Color.
Copying/pasting channels Open the channel’s context menu and select Copy or Paste.
See section ↑4.2.6, Copying and Pasting Sounds and ↑4.3.6, Copying and
Pasting Groups.
Resetting Sound channels Open the Sound channel’s context menu and select Reset.
See section ↑4.2.8, Resetting Sound Slots.
Controlling Your Mix
The Mixer
MASCHINE STUDIO - Manual - 405
