Even if the displays don’t switch to Mute or Solo mode, the usual procedures to mute and
solo Groups and Sounds stay valid in Mix mode. For more information on the Mute and So-
lo functions, please refer to section 5.2.2.
9.5.4 Plug-in Icons in Mix Mode
In Mix mode each channel depicts the presence of Plug-ins by little icons arranged vertically
on the right of the level meter:
A Sound channel with an Instrument Plug-in and three Effect Plug-ins.
Instrument and Effect Plug-ins are represented by different icons (these icons are similar to
those in the Plug-in List of the Arrange view).
On the displays you can see up to seven Plug-in icons in each channel. Any additional
Plug-in won’t be shown.
Controlling Your Mix
Controlling Your Mix from Your Controller
MASCHINE STUDIO - Manual - 435
