Element Description
SCALE Section
Velocity Adjusts the velocity response of the drum. Available values range from
-100.0 % to 100.0 % (default value). At zero (mid course), the drum is played
at full velocity, no matter how hard you hit the keys (or pads). From that mid
position, by turning the knob to the right you increase the positive velocity re-
sponse and make the drum more and more sensitive to the velocities at which
you hit the keys/pads. From the mid position, turning the knob to the left as
the inverse effect: the harder you hit the key/pad, the softer the resulting drum
sound will be.
10.2.2 Kick – Tronic
Fat, punchy and warm, the Tronic kick is based on another classic analog kick drum which has
provided the backbone to countless dance and electronic records for the past 30 years. The
Tronic kick takes this classic a step further with extended parameter ranges and chromatic
playability, but also adds a specially designed distortion section capable of a wide range of tex-
tures, from subtly rounded to all-out gabber assault.
The parameters described below are presented as they appear in the Control area (Arrange
view). The same parameters are available in the Plug-in panel within the Plug-in Strip (Mix
view). See ↑9.4, The Plug-in Strip for more information on this.
Main Page
Element Description
MAIN Section
Engine Selects the engine used in the Kick Plug-in. If you change this setting, please
refer to ↑10.2, The Kicks.
Tune Adjusts the pitch of the drum played by the middle C, measured in MIDI note
numbers and cents. Available values range from 31.00 to 55.00. The default
value is 43.00. For more details see ↑10.1.5, Pitch Range, Tuning, and MIDI
Notes.
Decay Adjusts the duration of the sound’s tail, measured as a percentage. Available
values range from 0.0 to 100.0 % (default: 50.0 %).
Using the Drumsynths
The Kicks
MASCHINE STUDIO - Manual - 445
