Element Description

Bend Adjusts the pitch sweep of the sound, measured as a percentage. Available val-

ues range from -100.0 % to 100.0 % (default: 0.0 %).

Focus Adjusts the attack of the sound as well as the speed and shape of the pitch en-

velope, to produce a different quality of attack and sharpness. Available values

range from 0.0 to 100 % (default: 50.0 %).

Advanced Page

For this engine the Advanced page does not contain any parameters.

Modulation Page

As with all other engines and Drumsynths, the Modulation page contains one parameter: Veloc-

ity.

Element Description

SCALE Section

Velocity Adjusts the velocity response of the drum. Available values range from

-100.0 % to 100.0 % (default value). At zero (mid course), the drum is played

at full velocity, no matter how hard you hit the keys (or pads). From that mid

position, by turning the knob to the right you increase the positive velocity re-

sponse and make the drum more and more sensitive to the velocities at which

you hit the keys/pads. From the mid position, turning the knob to the left as

the inverse effect: the harder you hit the key/pad, the softer the resulting drum

sound will be.

10.3.4 Snare – Sharp

The Sharp snare is an acoustic snare drum emulation inspired by the sound of 1970s disco

snares.

The parameters described below are presented as they appear in the Control area (Arrange

view). The same parameters are available in the Plug-in panel within the Plug-in Strip (Mix

view). See ↑9.4, The Plug-in Strip for more information on this.

Using the Drumsynths

The Snares

MASCHINE STUDIO - Manual - 462
