Element Description
Skin Tune Adjusts the fine-tuning of the skin of the drum, measured as a percentage.
Available values range from 0.0 to 100.0 % (default: 50.0 %).
Impact Adjusts how hard the drum is hit, measured as a percentage. Available values
range from 0.0 % (softest) to 100 % (hardest). The default value is 75.0 %.
Advanced Page
The Advanced page contains parameters controlling the wires’ sound of the drum.
Element Description
SPECTRA Section
Mode Selects from two different noise types that simulate the wires of the drum.
Available modes are A (default) and B.
Tune Provides an independent tuning of the snare noise. It relates to the tension of
the snare wires on a real snare drum. Available values range from 0.0 to
100.0 % (default: 50.0 %).
Decay Adjusts the length of the sound of the snare wires, independently from the
main Decay parameter on the Main page. Available values range from 0.0 % to
100.0 % (default: 40.0 %).
Amount Adjusts the amount of snare wire sound applied to the drum, measured as a
percentage. Available values range from 0.0 to 100.0 % (default: 75.0 %).
Modulation Page
As with all other engines and Drumsynths, the Modulation page contains one parameter: Veloc-
ity.
Using the Drumsynths
The Snares
MASCHINE STUDIO - Manual - 465
