MASCHINE 2.0 provides two different undo/redo features, each of them being suited for spe-

cific situations:

▪ Step Undo allows you to cancel your last single action.

▪ Take Undo allows you to cancel your last group of actions.

Step Undo

Step Undo/Redo is the classic undo/redo found in most applications. It cancels or re-executes

each single action you have performed.

In the software use the following keyboard shortcuts for the Step Undo and Step Redo func-

tions:

►

To cancel your last action (Step Undo), press [Ctrl]+[Shift]+[Z] ([Cmd]+ [Shift]+ [Z] on

Mac OS X). To re-execute your last action (Step Redo), press [Ctrl]+ [Shift]+ [Y] ([Cmd]+

[Shift]+ [Y] on Mac OS X). You can also select Undo Step and Redo Step from the Edit

menu in the Application Menu Bar or from the Edit submenu in the MASCHINE menu.

The commands in the Edit menu additionally shows which action will be undone/redone!

Take Undo

Suppose you have just recorded a 16th-note hi-hat beat over four bars, but then decide to can-

cel it. Normally you would have to cancel the 64 notes one at a time, repeatedly calling the

undo function 64 times in a row. This is what Take Undo has been made for!

Take Undo/Redo is an extended undo/redo available while recording that allows you to cancel

or re-execute a whole group of actions at once.

Take Undo/Redo is the default undo/redo in MASCHINE. In the software use the common key-

board shortcuts for the Undo and Redo functions:

►

To cancel your last group of actions, press [Ctrl]+[Z] ([Cmd]+[Z] on Mac OS X). To re-exe-

cute your last group of actions, press [Ctrl]+[Y] ([Cmd]+[Y] on Mac OS X). You can also

select Undo and Redo from the Edit menu in the Application Menu Bar or from the Edit

submenu in the MASCHINE menu.
