10.3.8 Snare – Iron

The Iron snare is an acoustic snare drum model that is capable of a metallic, bright sound.

The two modes available on its Advanced page select from two different snare wire characteris-

tics.

The parameters described below are presented as they appear in the Control area (Arrange

view). The same parameters are available in the Plug-in panel within the Plug-in Strip (Mix

view). See ↑9.4, The Plug-in Strip for more information on this.

Main Page

Element Description

MAIN Section

Engine Selects the engine used in the Snare Plug-in. If you change this setting, please

refer to ↑10.2.8, Kick – Push.

Tune Adjusts the pitch of the drum played by the middle C, measured in MIDI note

numbers and cents. Available values range from 46.00 to 70.00. The default

value is 58.00. For more details see ↑10.1.5, Pitch Range, Tuning, and MIDI

Notes.

Decay Adjusts the duration of the sound’s tail, measured as a percentage. Available

values range from 0.0 to 100.0 % (default: 50.0 %).

Skin Tune Adjusts the fine-tuning of the skin of the drum, measured as a percentage.

Available values range from 0.0 to 100.0 % (default: 50.0 %).

Impact Adjusts how hard the drum is hit, measured as a percentage. Available values

range from 0.0 % (softest) to 100.0 % (hardest). The default value is 75.0 %.

Body Adjusts the level of the snare body independently from level of the snare wires,

which is adjusted on the Advanced page (see below). Available values range

from 0.0 to 100.0 % (default: 75.0 %).

Advanced Page

The Advanced page contains parameters controlling the wires’ sound of the drum.

Using the Drumsynths

The Snares

MASCHINE STUDIO - Manual - 470
