Element Description
SPECTRA Section
Mode Selects from two different noise types that simulate the snare wires of the
drum. Available modes are A (default) and B.
Decay Controls the length of the snare wires’ sound independently from the main De-
cay parameter on the Main page. Available values range from 0.0 to 100.0 %
(default: 40.0 %).
Amount Adjusts the amount of snare wire sound applied to the drum, measured as a
percentage. Available values range from 0.0 to 100.0 % (default: 75.0 %).
Modulation Page
As with all other engines and Drumsynths, the Modulation page contains one parameter: Veloc-
ity.
Element Description
SCALE Section
Velocity Adjusts the velocity response of the drum. Available values range from
-100.0 % to 100.0 % (default value). At zero (mid course), the drum is played
at full velocity, no matter how hard you hit the keys (or pads). From that mid
position, by turning the knob to the right you increase the positive velocity re-
sponse and make the drum more and more sensitive to the velocities at which
you hit the keys/pads. From the mid position, turning the knob to the left as
the inverse effect: the harder you hit the key/pad, the softer the resulting drum
sound will be.
10.3.9 Snare – Clap
A stalwart of electronic music, the classic analog clap never really sounded like a group of peo-
ple clapping - but that makes it all the more iconic!
The parameters described below are presented as they appear in the Control area (Arrange
view). The same parameters are available in the Plug-in panel within the Plug-in Strip (Mix
view). See ↑9.4, The Plug-in Strip for more information on this.
Using the Drumsynths
The Snares
