Element Description
Color Adjusts the center frequency of the filter applied to the sound, measured in
hertz. Available values range from 932.3 Hz to 16.7 kHz (default: 7.4 kHz).
The default position gives a standard metallic analog hi-hat. Colored down, the
sound is much more melodic and in the midrange, good for percussion or ef-
fects. In a way this parameter is a more effective tuning control than the Tune
parameter itself. Note that the Color parameter also follows keyboard tracking
(i.e. the key/pad you play) along with the Tune parameter, limited to the range
of the parameter.
Saturate Adjusts the amount of analog-style saturation applied to the sound for in-
creased thickness, measured as a percentage. Available values range from 0.0
to 100.0 % (default: 19.0 %).
Noise Adjusts the mix between an oscillator bank and white noise as the signal
source, measured as a percentage. Available values range from 0.0 % (oscilla-
tor bank only) to 100.0 % (white noise only). The default value is 10.0 %.
Advanced Page
For this engine the Advanced page does not contain any parameters.
Modulation Page
As with all other engines and Drumsynths, the Modulation page contains one parameter: Veloc-
ity.
Element Description
SCALE Section
Velocity Adjusts the velocity response of the drum. Available values range from
-100.0 % to 100.0 % (default value). At zero (mid course), the drum is played
at full velocity, no matter how hard you hit the keys (or pads). From that mid
position, by turning the knob to the right you increase the positive velocity re-
sponse and make the drum more and more sensitive to the velocities at which
you hit the keys/pads. From the mid position, turning the knob to the left as
the inverse effect: the harder you hit the key/pad, the softer the resulting drum
sound will be.
Using the Drumsynths
The Hi-hats
MASCHINE STUDIO - Manual - 476
