10.4.2 Hi-hat – Circuit
Similar to the Silver hi-hat, the Circuit hi-hat uses a more complex oscillator for a more digital,
robotic sound.
The parameters described below are presented as they appear in the Control area (Arrange
view). The same parameters are available in the Plug-in panel within the Plug-in Strip (Mix
view). See ↑9.4, The Plug-in Strip for more information on this.
Main Page
Element Description
MAIN Section
Engine Selects the engine used in the Hi-hat Plug-in. If you change this setting, please
refer to ↑10.3.8, Snare – Iron.
Tune Adjusts the pitch of the cymbal played by the middle C, measured as a per-
centage. Available values range from 0.0 % to 100.0 % (default: 50.0 %). For
more details see ↑10.1.5, Pitch Range, Tuning, and MIDI Notes.
Decay Adjusts the duration of the sound, measured as a percentage. A short decay
produces a closed hat; a long decay gives an open hi-hat or cymbal. Available
values range from 0.0 to 100.0 % (default: 65.0 %).
Gate When enabled, the decay of the cymbal is choked by the end of the note. When
disabled (default), the cymbal plays as a one-shot sound, i.e. until the end of
its tail, no matter when the note is released, although the sound duration will
still depend on the Decay parameter (see above).
TONE Section
Color Adjusts the center frequency of the filter applied to the sound, measured in
hertz. Available values range from 932.3 Hz to 16.7 kHz (default: 7.4 kHz).
The default position gives a standard metallic analog hi-hat. Colored down, the
sound is much more melodic and in the midrange, good for percussion or ef-
fects. In a way this parameter is a more effective tuning control than the Tune
parameter itself. Note that the Color parameter also follows keyboard tracking
(i.e. the key/pad you play) along with the Tune parameter, limited to the range
of the parameter.
Using the Drumsynths
The Hi-hats
MASCHINE STUDIO - Manual - 477
