Element Description
Saturate Adjusts the amount of analog-style saturation applied to the sound for in-
creased thickness, measured as a percentage. Available values range from 0.0
to 100.0 % (default: 19.0 %).
Seed Selects a random sequence to control the waveform produced by the oscillator.
Each of the 31 seed values available produces a different set of random pitch-
es and harmonics.
Dissonance Affects the randomization of the oscillator, measured as a percentage. Availa-
ble values range from 0.0 to 100.0 % (default: 25.0 %). Higher values intro-
duce more randomization, resulting in a more noisy sound. Lower values pro-
duce a more melodic, oscillator-like sound.
Advanced Page
For this engine the Advanced page does not contain any parameters.
Modulation Page
As with all other engines and Drumsynths, the Modulation page contains one parameter: Veloc-
ity.
Element Description
SCALE Section
Velocity Adjusts the velocity response of the drum. Available values range from
-100.0 % to 100.0 % (default value). At zero (mid course), the drum is played
at full velocity, no matter how hard you hit the keys (or pads). From that mid
position, by turning the knob to the right you increase the positive velocity re-
sponse and make the drum more and more sensitive to the velocities at which
you hit the keys/pads. From the mid position, turning the knob to the left as
the inverse effect: the harder you hit the key/pad, the softer the resulting drum
sound will be.
10.4.3 Hi-hat – Memory
The Memory hi-hat is similar to a Romper-based cymbal but with a modern twist, using ana-
lyzed and reconstructed timbres rather than just a recorded sample.
Using the Drumsynths
The Hi-hats
