The parameters described below are presented as they appear in the Control area (Arrange
view). The same parameters are available in the Plug-in panel within the Plug-in Strip (Mix
view). See ↑9.4, The Plug-in Strip for more information on this.
Main Page
Element Description
MAIN Section
Engine Selects the engine used in the Hi-hat Plug-in. If you change this setting, please
refer to ↑10.3.8, Snare – Iron.
Tune Adjusts the pitch of the cymbal played by the middle C, measured as a per-
centage. Available values range from 0.0 % to 100.0 % (default: 50.0 %). For
more details see ↑10.1.5, Pitch Range, Tuning, and MIDI Notes.
Decay Adjusts the duration of the sound, measured as a percentage. Available values
range from 0.0 to 100.0 % (default: 65.0 %). A short decay produces a closed
hat; a long decay gives an open hi-hat or cymbal.
Gate When enabled, the decay of the cymbal is choked by the end of the note. When
disabled (default), the cymbal plays as a one-shot sound, i.e. until the end of
its tail, no matter when the note is released, although the sound duration will
still depend on the Decay parameter (see above).
Source Selects the sampled timbre to be used as source. Six modes are available — A
(default), B, C, D, E, and F — each corresponding to a different cymbal.
TONE Section
Color Adjusts the frequency curve of the sound, measured as a percentage. Available
values range from 0.0 to 100.0 % (default: 71.5 %). Higher settings produce a
brighter sound; lower settings produce a more boxy sound.
Strike Adjusts the attack of the cymbal, measured as a percentage. Available values
range from 0.0 to 100.0 % (default: 75.0 %).
Distress Introduces even more lo-fi grit, crushing and distortion. Available values range
from 0.0 % (default) to 100.0 %.
Advanced Page
For this engine the Advanced page does not contain any parameters.
Using the Drumsynths
The Hi-hats
MASCHINE STUDIO - Manual - 479
