Element Description
Bend Adjusts the pitch sweep of the sound, measured as a percentage. Available val-
ues range from -100.0 % to 100.0 % (default: 0.0 %). At zero the sound stays
at its original pitch during its entire decaying phase. At higher values, the pitch
bends upwards. At lower values, the pitch bends downwards.
Impact Adjusts the amount of attack, measured as a percentage. Available values
range from 0.0 % (soft attack) to 100.0 % (maximum attack). The default val-
ue is 80.0 %.
Advanced Page
The Advanced page contains parameters controlling the individual oscillators.
Element Description
HARMONICS Section
Interval Adjusts the interval between the two oscillators, measured in semitones and
cents. Available values range from -0.50 to 13.50 (default: 6.50). At low val-
ues the oscillators are tuned close together, giving a detuned sound which can
be used for basslines.
FM Freq Adjusts the frequency of the FM oscillator, measured as a percentage. Availa-
ble values range from 0.0 to 100.0 % (default: 50.0 %).
FM Decay Adjusts the decay of the FM oscillator, measured as a percentage. Available
values range from 0.0 to 100.0 % (default: 35.0 %). Short decays are useful
to supplement the attack or impact of the tom. Long decays can be used to
embellish the tone or timbre of the tom, especially when applied subtly (see
FM Amount below).
FM Amount Adjusts the amount of frequency modulation applied by the FM oscillator,
measured as a percentage. Available values range from 0.0 to 100.0 % (de-
fault: 10.0 %). At 0.0 % there is no frequency modulation so the other FM
controls (FM Freq and FM Decay) have no effect.
Modulation Page
As with all other engines and Drumsynths, the Modulation page contains one parameter: Veloc-
ity.
Using the Drumsynths
The Toms
MASCHINE STUDIO - Manual - 483
