Element Description
SCALE Section
Velocity Adjusts the velocity response of the drum. Available values range from
-100.0 % to 100.0 % (default value). At zero (mid course), the drum is played
at full velocity, no matter how hard you hit the keys (or pads). From that mid
position, by turning the knob to the right you increase the positive velocity re-
sponse and make the drum more and more sensitive to the velocities at which
you hit the keys/pads. From the mid position, turning the knob to the left as
the inverse effect: the harder you hit the key/pad, the softer the resulting drum
sound will be.
10.5.2 Tom – Fractal
The Fractal tom is a modern electronic tom with a broad sonic range from pure and analog-
sounding through organic and percussive through bell-like to totally alien. It uses a tone oscil-
lator and a feedback oscillator bank (like the one used in the Fractal engine of the Percussion,
see ↑10.6.1, Percussion – Fractal), the balance between which is controlled by the Mix param-
eter on the Advanced page. The tone oscillator on its own produces a simple analog-style blee-
py tom. The addition of the feedback oscillator bank facilitates a much wider range of sounds.
The parameters described below are presented as they appear in the Control area (Arrange
view). The same parameters are available in the Plug-in panel within the Plug-in Strip (Mix
view). See ↑9.4, The Plug-in Strip for more information on this.
Main Page
Element Description
MAIN Section
Engine Selects the engine used in the Tom Plug-in. If you change this setting, please
refer to ↑10.5, The Toms.
Tune Adjusts the pitch of the drum played by the middle C, measured in MIDI note
numbers and cents. Available values range from 48.00 to 72.00. The default
value is 48.00. For more details see ↑10.1.5, Pitch Range, Tuning, and MIDI
Notes. Note that the pitch of this instrument is heavily dependent on the set-
tings on the Advanced page (see below).
Decay Adjusts the duration of the sound’s tail, measured as a percentage. Available
values range from 0.0 to 100.0 % (default: 50.0 %).
Using the Drumsynths
The Toms
MASCHINE STUDIO - Manual - 484
