Element Description
Bend Adjusts the pitch sweep of the sound, measured as a percentage. Available val-
ues range from -100.0 % to 100.0 % (default: 0.0 %). At zero the sound stays
at its original pitch during its entire decaying phase. At higher values, the pitch
bends upwards. At lower values, the pitch bends downwards.
Impact Adjusts the amount of attack, measured as a percentage. Available values
range from 0.0 % (soft attack) to 100.0 % (maximum attack). The default val-
ue is 80.0 %.
Color Adjusts a simple filter which affects the brightness of the sound. Available val-
ues range from 0.0 to 100.0 % (default: 50.0 %).
Glide The tuning of the Fractal tom is locked for each note; in other words the
change in tuning is applied only when a new note is received. When the Glide
parameter is set higher than zero, the pitch glides smoothly to the new tuning.
The Glide parameter then defines the duration this glide takes, measured in
milliseconds: as you increase the Glide value, the glide gets slower and more
audible. This also applies when the tom is played across the keyboard. Availa-
ble values range from None (no glide) to 350.0 ms (slowest glide). The default
value is 5.5 ms.
Advanced Page
The Advanced page contains parameters controlling the individual oscillators.
Element Description
HARMONICS Section
KTr. Mode (Key Tracking
Mode)
Selects from two key tracking modes: Harmonic (default) and Dissonant.
In Harmonic mode all oscillators track the Tune parameter (on the Main page,
see above) and your keyboard evenly. Therefore, the drum stays in tune with it-
self as the Tune parameter is adjusted, and can be played chromatically across
the keyboard.
In Dissonant mode the oscillators track the Tune parameter of your keyboard/
pads unevenly. Therefore, the drum produces dissonant, detuned harmonics
when the Tune parameter is adjusted or when you play different notes.
Mix Adjusts the mix between the tone oscillator and the feedback oscillator bank,
measured as a percentage. Available values range from 0.0 % (tone oscillator
only) to 100.0 % (feedback oscillator bank only). The default value is 5.0 %.
Using the Drumsynths
The Toms
MASCHINE STUDIO - Manual - 485
