Element Description
Transpose Adjusts the pitch transposition of the feedback oscillator bank only, measured
in semitones and cents. This is useful for tuning it to the tone oscillator. Avail-
able values range from -12.00 to 12.00 semitones (default: 0.00).
Freq A Adjusts the pitch of oscillator A within the feedback oscillator bank, measured
as a percentage. Available values range from 0.0 to 100.0 % (default).
Freq B Adjusts the pitch of oscillator B within the feedback oscillator bank, measured
as a percentage. Available values range from 0.0 to 100.0 % (default:
75.0 %). Note that this control has no effect when FM and AM are set to zero
(see below).
FM Adjusts the amount of frequency modulation within the feedback oscillator
bank, measured as a percentage. Frequency modulation tends to add bell-like,
ringing overtones. Available values range from 0.0 to 100.0 % (default:
50.0 %).
AM Adjusts the amount of amplitude modulation within the feedback oscillator
bank, measured as a percentage. Amplitude modulation tends to add brash,
bright overtones. Available values range from 0.0 to 100.0 % (default:
50.0 %).
Modulation Page
As with all other engines and Drumsynths, the Modulation page contains one parameter: Veloc-
ity.
Element Description
SCALE Section
Velocity Adjusts the velocity response of the drum. Available values range from
-100.0 % to 100.0 % (default value). At zero (mid course), the drum is played
at full velocity, no matter how hard you hit the keys (or pads). From that mid
position, by turning the knob to the right you increase the positive velocity re-
sponse and make the drum more and more sensitive to the velocities at which
you hit the keys/pads. From the mid position, turning the knob to the left as
the inverse effect: the harder you hit the key/pad, the softer the resulting drum
sound will be.
Using the Drumsynths
The Toms
MASCHINE STUDIO - Manual - 486
