Element Description
Skin Adjusts the amount of damping applied to the drum skin, measured as a per-
centage. Available values range from 0.0 % (default) to 100.0 %.
Air Adjusts the amount of damping applied to the air, measured as a percentage.
Available values range from 0.0 to 100.0 % (default: 50.0 %).
Advanced Page
For this engine the Advanced page does not contain any parameters.
Modulation Page
As with all other engines and Drumsynths, the Modulation page contains one parameter: Veloc-
ity.
Element Description
SCALE Section
Velocity Adjusts the velocity response of the drum. Available values range from
-100.0 % to 100.0 % (default value). At zero (mid course), the drum is played
at full velocity, no matter how hard you hit the keys (or pads). From the mid
position, by turning the knob to the right you increase the positive velocity re-
sponse and make the drum more and more sensitive to the velocities at which
you hit the keys/pads. From the mid position, turning the knob to the left as
the inverse effect: the harder you hit the key/pad, the softer the resulting drum
sound will be.
10.6 The Percussions
The Percussion Drumsynth can generate a variety of percussion sounds.
The Percussion in the Control area (Main page depicted).
Using the Drumsynths
The Percussions
MASCHINE STUDIO - Manual - 488
