Element Description
Glide Adjusts the glide between the pitch of new notes, measured in milliseconds.
When the Glide parameter is set higher than zero, the pitch glides smoothly to
the new tuning. The Glide parameter then defines the duration this glide takes.
Available values range from None (no glide, default) to 762.8 ms.
Impact Adjusts the amount of attack, measured as a percentage. Available values
range from 0.0 % (soft attack) to 100.0 % (maximum attack). The default val-
ue is 60.0 %.
Advanced Page
The Advanced page contains parameters controlling the individual oscillators.
Element Description
HARMONICS Section
KTr. Mode (Key Tracking
Mode)
Selects from two key tracking modes: Harmonic (default) and Dissonant.
In Harmonic mode all oscillators track the Tune parameter (on the Main page,
see above) and your keyboard evenly. Therefore, the drum stays in tune with it-
self as the Tune parameter is adjusted, and can be played chromatically across
a keyboard or the pads.
In Dissonant mode the oscillators track the Tune parameter you’re your key-
board) unevenly. Therefore, the drum produces dissonant, detuned harmonics
when the Tune parameter is adjusted or when you play different notes on a key-
board or the pads.
Freq A Adjusts the pitch of oscillator A within the feedback oscillator bank, measured
as a percentage. Available values range from 0.0 to 100.0 % (default:
50.0 %).
Freq B Adjusts the pitch of oscillator B within the feedback oscillator bank, measured
as a percentage. Available values range from 0.0 to 100.0 % (default:
50.0 %). Note that this parameter has no effect when FM and AM are set to
zero (see below).
Freq C Adjusts the pitch of oscillator C within the feedback oscillator bank, measured
as a percentage. Available values range from 0.0 to 100.0 % (default:
29.1 %). Note that this parameter has no effect when FM and AM are set to
zero (see below).
Using the Drumsynths
The Percussions
MASCHINE STUDIO - Manual - 491
