Element Description
SCALE Section
Velocity Adjusts the velocity response of the drum. Available values range from
-100.0 % to 100.0 % (default value). At zero (mid course), the drum is played
at full velocity, no matter how hard you hit the keys (or pads). From that mid
position, by turning the knob to the right you increase the positive velocity re-
sponse and make the drum more and more sensitive to the velocities at which
you hit the keys/pads. From the mid position, turning the knob to the left as
the inverse effect: the harder you hit the key/pad, the softer the resulting drum
sound will be.
10.6.3 Percussion – Shaker
The Shaker is a versatile electronic shaker/maraca engine.
The parameters described below are presented as they appear in the Control area (Arrange
view). The same parameters are available in the Plug-in panel within the Plug-in Strip (Mix
view). See ↑9.4, The Plug-in Strip for more information on this.
Main Page
Element Description
MAIN Section
Engine Selects the engine used in the Percussion Plug-in. If you change this setting,
please refer to ↑10.5.3, Tom – Floor.
Tune Adjusts the center frequency of the filter applied to the noise source, which will
define the pitch of the drum played by the middle C, measured as a percent-
age. Available values range from 0.0 % to 100.0 % (default: 50.0 %). For
more details see ↑10.1.5, Pitch Range, Tuning, and MIDI Notes.
Filter Adjusts the bandwidth of the filter applied to the noise source, measured as a
percentage. Higher settings result in a wider filter. Lower settings result in a
narrower filter, measured as a percentage. Available values range from 0.0 to
100.0 % (default: 70.0 %).
Grain Adjusts the timbre of the noise source, measured as a percentage. Higher set-
tings emulate the grainy sound of a real shaker. Available values range from
0.0 to 100.0 % (default: 50.0 %). Furthermore the Grain parameter is as-
signed to velocity: lower velocity shakes are more grainy.
Using the Drumsynths
The Percussions
MASCHINE STUDIO - Manual - 494
