The Sound slot now mirrors the Plug-in name.
For more information on renaming Sound slots, see section ↑4.2.3, Renaming Sound Slots.
11.3.1.1 Set Up a Sound as Send Effect on the MASCHINE STUDIO Controller
1. Press the PLUG-IN button to enter Control mode and show the Plug-in slots.
2. Press Button 3 to select the SOUND tab
3. Press the Group button A–H of the Group containing the empty Sound you want to use. If
the Group in question is in another bank, before you select the Group you first need to
press SHIFT + the corresponding Group button A–H to select its Group bank.
4. Press SELECT + the unlit pad of the empty Sound you want to use (or simply hit its unlit
pad if pads are in Group mode).
Since we have selected an empty Sound, you see (NONE) under Button 7/8 and these but-
tons are inactive (i.e. there are no Plug-ins to navigate yet).
5. Press SHIFT + BROWSE to open the Plug-in Browser and browse the available Instrument
and Effect Plug-ins.
6. Turn Knob 1 (TYPE) to choose between MASCHINE internal instruments and effects (Inter-
nal), VST/AU plug-ins from Native Instruments (NI) or VST/AU plug-ins from third-party
manufacturers (External).
Using Effects
Creating a Send Effect
MASCHINE STUDIO - Manual - 518
