Parameter Description

MODE Section

Mode Selects between two operation modes: Classic (default setting) and Feed-

back. Whereas Classic mode generates a cleaner and more precise com-

pression, Feedback mode introduces a subtle change in transient shape

and frequency responsiveness. The memory-based envelope detection

along with the knee-dependent ratio and gain give this mode a typical vin-

tage feel.

DEPTH Section

Threshold This value determines the threshold at which the Compressor starts to

work.

Knee This parameter defines how the Compressor starts to work: with a low set-

ting, the transition into compression is soft, whereas with a high setting,

the Compressor abruptly starts to work once the threshold is reached.

Amount The amount of compression effect, often called ratio in typical applica-

tions.

TIME Section

Attack Use Attack to adjust how fast the Compressor reacts on the incoming sig-

nal: the more you dial it to the right, the slower it will react. Longer Attack

times let more transients through.

Release The time the compressor will take to stop compressing after the input sig-

nal falls below the threshold. With longer release times it takes more time

to get back to normal.

OUTPUT Section

Gain Use Gain to adjust the volume of the resulting signal; sometimes called

“make-up gain” as it can be used to compensate for any reduction in the

signal induced by the settings above.

Effect Reference

Dynamics

MASCHINE STUDIO - Manual - 528
