The Compressor on the controller: MAIN page.
Side-Chain Input Page
The Compressor in the Control area: Side-Chain Input page.
Parameter Description
INPUT Section
Source Selects the audio signal you want to use as side-chain signal to control the
Plug-in. Available options are None (side-chain disabled, default setting), the
outputs of all (other) Sounds , and the outputs of all (other) Groups.
In the menu these outputs are labeled as follows:
For Groups: [Group name] (e.g., Drums)
For Sounds: [Group name]: [Sound name] (e.g., Drums: Kick)
In the selector display these outputs are labeled as follows:
For Groups: [Group name] (e.g., Drums)
For Sounds: [Group letter+number]:S[Sound number] (e.g., A1:S4 for the Sound
4 of Group A1)
Effect Reference
Dynamics
MASCHINE STUDIO - Manual - 529
