2.4.2 Switching Instances
When two or more instances of the MASCHINE software are running (e.g., as plug-ins on dif-
ferent tracks of your DAW), you must choose which instance you want to control from your
hardware controller. You can do this both from your controller and in the software.
Click the Connect button to connect the controller to that instance.
►
To select your controller from a particular MASCHINE instance, click the Connect button
in the MASCHINE Header of that instance.
2.4.2.1 Switching Instances from the MASCHINE STUDIO Controller
To switch from one MASCHINE instance to another:
1. Press SHIFT + PLUG-IN.
2. Turn the jog wheel to select the desired instance.
3. Press Button 4 to load that instance.
You can also use Knob 5 or Button 5 and 6 to select the desired instance, and Button 8 to
load it.
2.4.3 Controlling Various Instances with Different Controllers
You can use two or more MASCHINE controllers of different types (MASCHINE STUDIO, MA-
SCHINE MK2, MASCHINE MIKRO MK2, MASCHINE, and MASCHINE MIKRO) simultaneously
with different instances of the MASCHINE software (possibly with one instance in stand-alone
mode). In doing so, the following applies:
▪ Only one MASCHINE controller of any type can be connected to an instance at a time.
You can choose which instance you want to control from each controller as described in
↑2.4.2, Switching Instances.
▪ When you start a new instance of the MASCHINE software, it connects to one of the MA-
SCHINE controllers according to following precedence rules:
Basic Concepts
Stand-Alone and Plug-in Mode
MASCHINE STUDIO - Manual - 53
