Parameter Description

Gain Adjusts the input level of the side-chain signal fed into the Plug-in.

FILTER Section

Filter Activates a filter on the side-chain input. This filter can be useful to select only

a specific frequency range of the side-chain signal to control the Plug-in.

Center Freq Adjusts the center frequency of the filter.

Width Adjusts the bandwidth of the filter.

On your controller the outputs available in the SOURCE parameter are labeled as in the dis-

play of the Source selector described above.

For more information on how to use the side-chain input, please refer to section ↑11.1.3,

Using the Side-Chain Input.

The Compressor on the controller: SIDE-CHAIN INPUT page.

Level Meters in the Compressor Panel (Plug-in Strip)

In the Plug-in Strip, the Compressor panel offers a few extra features not available in the Con-

trol area:

▪ The Threshold and Gain faders (corresponding to the Threshold and Gain parameters of

the Main page in the Control area) provide level meters for visual monitoring of the input

and output levels. In particular, by comparing the input level with the position of the

Threshold fader, you can easily see you which parts of the signal will be compressed, and

adjust the Threshold fader accordingly.

Effect Reference

Dynamics

MASCHINE STUDIO - Manual - 530
