▪ An additional GR level meter indicates the gain reduction currently applied by the Com-
pressor to the input signal.
12.1.2 Gate
The Gate cuts any part of the input signal which falls below the input threshold. This can be
used to rhythmically chop the signal and make it stutter or sound staccato.
If this effect is used in a Sound or a Group, it also provides a Side-Chain Input page (in the
Control area and on your controller).
The Gate panel in the Plug-in Strip.
Main Page
The Gate in the Control area: Main page.
Parameter
Description
DEPTH Section
Threshold This value determines the threshold at which the Gate starts to work. High-
er values will let only the loudest parts of the signal through the Gate.
Effect Reference
Dynamics
MASCHINE STUDIO - Manual - 531
