Parameter Description
TIME Section
Attack Use Attack to adjust how fast the Gate reacts to the incoming signal: the
more you dial it to the right, the slower it will react, resulting in a softer
transition between the gated and the not gated parts of the signal.
Hold The Hold parameter is used to determine how long the gated signal is held;
lower values will result in a more "choppy" effect.
Release The time the Gate will take to release the input signal after it rises above
the threshold.
OUTPUT Section
Mix Mix lets you adjust the amount of the effect in relation to the dry original
audio signal.
The Gate on the controller: MAIN page.
Side-Chain Input Page
The Gate in the Control area: Side-Chain Input page.
Effect Reference
Dynamics
MASCHINE STUDIO - Manual - 532
