The Transient Master panel in the Plug-in Strip.
The Transient Master in the Control area.
Parameter Description
DEPTH Section
Input Gain Adjusts the level of the input signal. This allows you to offset the overall level
once you have set the desired effect, in order to counterbalance the gain or
loss of level that might occur.
Attack Sharpens/softens the attack phases in your signal. With the knob at the middle
position, the attack phases are not altered. From this position, turning the At-
tack knob to the left softens the attack phases, while turning it to the right
sharpens them.
Sustain Prolongs/shortens the sustain phases in your signal. With the knob at the mid-
dle position, the sustain phases are not altered. From this position, turning the
Sustain knob to the left shortens the sustain phases, while turning it to the
right prolongs them.
Limit Activates a hard limiter at the output, preventing the output signal from clip-
ping. This can be useful when the Attack knob is set to a high value as this
may produce amplified attack phases which become too loud.
Effect Reference
