◦ Rule 1: The MASCHINE STUDIO controller focus has priority over the MK2 controllers
(MASCHINE MK2 and MASCHINE MIKRO MK2), which themselves take priority over
legacy controllers (MASCHINE and MASCHINE MIKRO).
◦ Rule 2: The MASCHINE controllers (legacy and MK2) have priority focus over MA-
SCHINE MIKRO controllers (legacy and MK2).
◦ Rule 1 has priority over rule 2.
2.4.4 Controlling your Host’s Transport Functions in Plug-in Mode
When you are using MASCHINE as a plug-in within a host application, the Host Transport Con-
trol feature allows you to split the control elements of your controller into two groups:
▪ All buttons in the TRANSPORT section except REC, SHIFT, and GRID control your host
application via MIDI.
▪ All other elements control the MASCHINE plug-in instance.
This allows you to simultaneously control the transport functions of your host and the various
elements of your MASCHINE Project!
The Host Transport Control can be activated in the MIDI Template loaded in the Controller Edi-
tor. When MASCHINE is loaded as a plug-in in your host application, do the following:
1. Start the Controller Editor.
2. In the Device menu in the top left corner of the Controller Editor window, select the entry
corresponding to your controller in order to edit its MIDI assignments of your MASCHINE
STUDIO Controller.
3. In the Templates page on the right, click the desired MIDI Template to load it.
4. Click the Host Transport Control option under the Template List to enable/disable it.
→
From now on the buttons in the TRANSPORT section (except REC, SHIFT, and GRID) will
send MIDI data as specified in the Template loaded in the Controller Editor, while all oth-
er elements will control the MASCHINE plug-in instance.
For more information on the MIDI mode, please refer to the Controller Editor Manual.
