Parameter Description
Gain Adjusts the input level of the side-chain signal fed into the Plug-in.
FILTER Section
Filter Activates a filter on the side-chain input. This filter can be useful to select only
a specific frequency range of the side-chain signal to control the Plug-in.
Center Freq Adjusts the center frequency of the filter.
Width Adjusts the bandwidth of the filter.
On your controller the outputs available in the SOURCE parameter are labeled as in the dis-
play of the Source selector described above.
For more information on how to use the side-chain input, please refer to section ↑11.1.3,
Using the Side-Chain Input.
The Maximizer on the controller: SIDE-CHAIN INPUT page.
Effect Reference
Dynamics
MASCHINE STUDIO - Manual - 542
