The Flanger in the Control area.
Parameter Description
MAIN Section
Frequency This defines the center frequency of the Flanger.
Feedback Adjusts the amount of output signal fed back into the input.
Invert Inverts the Flanger.
MOD Section
Amount This defines how much the Flanger gets modulated by the modulation source.
Source Here you can select the modulation source of the Flanger: available options are
LFO, LFO Sync, and Envelope. Depending on your selection, the parameter to
the right will change.
Speed (LFO) Defines the speed of the LFO in a range from 0.03 Hz up to 8 Hz.
Speed (LFO Sync) Defines the speed of the LFO in note values from 16/1 (one cycle every 16
bars) up to 1/16 note.
Shape (Envelope) Change the shape of the envelope here.
Stereo This parameter widens the stereo field of the effect.
OUTPUT Section
Mix Mix lets you adjust the amount of the effect in relation to the dry original audio
signal.
Effect Reference
Modulation Effects
MASCHINE STUDIO - Manual - 552
