Parameter Description
FREQ Section
Rate This is for adjusting the speed of the FM modulation.
Split The Split control determines the extent to which the FM effect is applied
to high frequencies via a crossover. Turn to the right to affect higher fre-
quencies. It can be useful to eliminate noise artifacts caused by FM of very
high signals.
With high Split settings, the effect becomes more “gritty” and crackling.
DEPTH Section
Contour Contour determines the extent to which the input volume affects the inten-
sity of the effect.
Amount Determines the amount of the FM effect.
The FM on the controller.
12.3.4 Freq Shifter
The Freq Shifter shifts selected frequencies of the audio signal by a user-specified amount.
With high frequencies it sounds like a pitch shifter; with low frequencies it sounds like a spe-
cial chorus.
Effect Reference
Modulation Effects
MASCHINE STUDIO - Manual - 554
